The ion contamination tester can simply and accurately measure ion concentration, and it is compatible with major international standards, including MIL-P-28809, MIL-STD-2000A, DEF-STD 10/03, IPC-TR-583, IEC, etc. Through the measurement of ion contamination level, potential problems can be detected immediately, thus ensuring the reliability and durability of your final products.
Features 1. Fully compatible with international standards 2. New-type test tank for precise and simple testing 3. Customizable cleaning tanks available upon request 4. Fully automatic testing 5. User-friendly interface for easy operation 6. Intuitive result display
| Model | CT100 | CT1000 |
|---|---|---|
| Cleaning Tank Size | 80x250x300mm | 70x700x700mm |
| Chemical Solvent | 50% or 75% IPA/DI water | |
| Resin | Replaceable, 1 litre of resin | |
| Measurement Range | 0.01 to 20.00 μgEq NaCl/cm² | |
| Sensitivity | 0.0001 μS/cm (0.003 μgEq NaCl/cm²) | |
| Power Supply | 230VAC, 50Hz | |
| Weight | 17Kg | |
| Dimensions | WxDxH: 510x315x590mm |
